DaqPro 5300

DaqPro 5300

• Handheld-Datenlogger with 8 input channels for Pt100 (8x2- or 4x3-wire), Thermocouple type J, K and T, Thermistors (2,252 kOhm or 10 kOhm)
• for more details see the universal dataloggers

HT220

Data logger HT200/HT220/HT225

• perfect for preocess monitoring in the food industry, pharmaceutical industrie, for the control of incubators or autoclaves
• waterproof case constructed of food grade stainless steel
• for extreme conditions (-40 °C to 125 °C)
• precision: ±1°C from -20°C to 100 °C
• memory: 32000 points
• sample interval: 10 seconds to 24 hours in 10 seconds increments
• download time: 45 seconds, typical when not logging
• maximale pressure: 50 PSI
• 3.6 V lithium battery included
• battery life (average): 5 years
• USB interface
• software for data transfert: ref. A016
• 21CFR11 software for data transfert, ref. A026

dimensions and specific description

• HT200: case 13.6 cm x 1.9 cm - respons time 15 minutes to move 63% of full scale
• HT220: case 13.6 cm x 1.9 cm - piercing probe 6 cm x 0.5 cm- respons time 5 minutes to move 63% of full scale
• HT225: case 13.6 cm x 1.9 cm - piercing probe 12.3 cm x 0.3 cm- respons time 5 minutes to move 63% of full scale

Data logger SK500

• temperature range: -20 to +70 °C
• sensor integrated in the box
• precision: ±1 °C
• respons time: 10 minutes to move 63% of full scale
• memory: 7936 points
• sample interval: 10 seconds to 24 hours in 10 seconds increments
• download time: about 30 seconds, RS232 interface
• ambient operating conditions: -20 to 70°C, 0 to 95 % RH non-condensing
• 3.6 V lithium battery included
• battery life (average): 1 year
• weight 12.4 g
• software for data transfert: ref. A015
• 21CFR11 software for data transfert, ref. A025

Data logger SK550

• temperature range: -20 to +70 °C
• sensor integrated in the box
• precision: ±1 °C
• respons time: 10 minutes to move 63% of full scale
• memory: 7936 points
• sample interval: 10 seconds to 24 hours
• download time: about 30 seconds, USB interface
• ambient operating conditions: -20 to 70°C, 0 to 95 % RH non-condensing
• 3.6 V lithium battery included
• battery life (average): 1 year
• weight 23 g
• dimensions: 4.45 x 3.48 x 1.57 cm
• software for data transfert: ref. A016 and SW400 for calibration
• 21CFR11 software for data transfert, ref. A026

Data logger 'Report Logger'

Temperature Report LoggerThe report logger is a simple temperature data logger. It requires no software to view the logged data. Plug the logger into one of the USB ports on your computer, open the application and quickly generate reports from the logged data.

• PDF, JPEG, or raw data (.txt) report formats
• no software required
• push-to-start
• user-replaceable battery (CR2450 Coin Cell Battery)
• low cost
• weight: 50 g
• dimensions: L 92 mm x W 43 mm, D 23 mm
• precision: 1 °C
• PC Requirements: Windows XP, Vista or 7, 1 available USB port

Available Models

SP425

Data logger SP425

• temperature range: -20°C to +70°C
• sensor integrated in the box
• precision: ±1 °C, displays min/max
• fonction push to start
• memory: 32000 points
• sample interval: 1 second to 24 hours in 1 second increments
• ambient operating conditions: -20 to 70 °C, 0 to 95 % RH non-condensing
• 123A lithium battery included (user replaceable)
• battery life (average): 1 year
• weight: 120 g
• software for data transfert: ref. A016 (USB)
• 21CFR11 software for data transfert, ref. A026

SP125

Data logger SP125

• temperature range: -23°C to +80°C
• sensor integrated in the box
• precision: ±0,7 °C
• memory: 32000 points
• sample interval: 10 seconds to 24 hours in 10 seconds increments
• ambient operating conditions: -23 to 80°C, 0 to 95 % RH non-condensing
• Alarm: LED flashes Red when High/Low Limits are met
• 3 V lithium battery included (user replaceable)
• battery life (average): 1 year
• weight: 53 g
• software for data transfert: ref. A016 (USB)
• 21CFR11 software for data transfert, ref. A026

SP175

Data logger SP175

• 2 channels
• temperature range for channel 1, sensor integrated in the box: -23°C to +80°C
• temperature range for channel 2, with optional external sensor thermocouple K: -150°C to +1100°C
• precision: ±1°C for both channels
• memory: 32000 points
• sample interval: 10 seconds to 24 hours in 10 seconds increments
• ambient operating conditions: -23 to 80°C, 0 to 95 % RH non-condensing
• Alarm: LED flashes Red when High/Low Limits are met
• 3 V lithium battery included (user replaceable)
• battery life (average): 1 year
• weight: 53 g
• software for data transfert: ref. A016 (USB)
• 21CFR11 software for data transfert, ref. A026
• sensor A203 (thermocouple K)

SM300

SM320

SM325

SM420

SM720

SM725

Data logger SM300/SM320/SM325/SM420/SM720/SM725

SM300 specific description

• temperature range: -20 °C to +70 °C
• precision: ±0.5 °C
• respons time: 2.5 minutes

SM320 specific description

• temperature range for channel 1: -20 °C to +70 °C
• temperature range for channel 2: -184 °C to +204 °C with standard thermocouple, -184 °C to 1093 °C with thermocouple A203
• precision for channel 1: ±0,5 °C
• precision for channel 2: ±1 °C
• respons time: 2.5 minutes

SM325 specific description

• temperature range for both channels -184 °C to +204 °C with standard thermocouple, -184 °C to 1093 °C with thermocouple A203
• precision: ±1 °C
• respons time: 1 minutes to move 63% of full scale

SM420 specific description

• one channel only
• temperature range: -45 °C to +176 °C with PRTD sensor
• precision: ±0,28 °C
• respons time: 3 minutes

SM720 specific description

• like SM320 with ethernet connection
• download time: about 2 minutes

SM725 specific description

• like SM325 with ethernet connection
• download time: about 2 minutes

commun description

• affichage de la température minimale et maximale
• alarme
• memory: 32000 points (16000 par canal pour les enregistreurs bicanaux)
• sample interval: 1 second to 24 hours in 1 or 10 seconds increments
• data download with RS232, USB or memory card
• download time: about 1.5 minutes with RS232 or 30 seconds with USB
• ambient operating conditions: -20 to 70°C, 0 to 95 % RH non-condensing
• 4 AA batteries included or 220 V/ 9 V adapter
• battery life (average): 6 months
• software for data transfert: ref. A015 (RS232) or A016 (USB)
• 21CFR11 software for data transfert, ref. A025 (RS232) or A026 (USB)

• Measurement Range: -35 to +80°C
• Memory: 16,382 readings
• USB Interface for Set-up and Data Download
• 2 User-Programmable Alarm Thresholds
• Bright Red, Green and Orange LED Indication
• Replaceable Internal Lithium Battery
• IP 67 Protection
• Resolution: 0.5 °C
• 1/2 AA 3.6V Lithium Battery Life: 1 year

• for external sensors
• -200 to +1300°C Measurement Range (K-type)
• -130 to +900°C Measurement Range (J-type)
• -200 to +350°C Measurement Range (T-type)
• memory: 32000 points
• Logging Rate: 1s, 10s, 1m, 5m, 30m, 1hr, 6hr, 12hr
• USB Interface for Set-up and Data Download
• 2 User-Programmable Alarm Thresholds
• Bright Red and Green LED Indication
• Replaceable Internal Lithium Battery
• Supplied with basic K-type thermocouple rated from 0 to 110°C (32 to 230°F)
• Resolution: 0.5 °C
• 1/2 AA 3.6V Lithium Battery Life: 6 months

FT500

Data logger FT500

• one internal sensor
• temperature range: -18 to +40°C
• precision: ±0.7 °C
• alarm (Sound + Text)
• memory: 64000 points (display 250 points)
• recording intervall: 1 Hour, 8 Hours, 1 Day, 3 Days, 7 Days, or Custom (up to 10 Sec)
• operating conditions: -18 to 50°C, 0 to 95 % RH non-condensing
• 230 V/ 9 V adapter included
• backup with 9 V battery
• battery life (average): 2 weeks
• display: 15 x 11 cm, touchscreen, multiple screen views, on-screen zoom and scroll
• weight: 600 g
• data tranfer with USB cable or flash memory card
• software for data transfert: ref. A016 and SW400 for the calibration
• 21CFR11 software for data transfert, ref. A026

FT525

Data logger FT525

• like FT500 but with external sensor (thermistor)
• temperature range: -40 to 149 °C
• precision: ±0.3 °C from -28 to 80C; ±0.7 °C remaining range
• operating conditions: -18 to 50°C, 0 to 95 % RH non-condensing

FT520, FT 530

Data logger FT520, FT530

• like FT500 but with one (FT520) or 2 (FT300) external type K thermocouple
• temperature range: -184 to 1090 °C
• precision: ±1 °C
• operating conditions: -18 to 50°C, 0 to 95 % RH non-condensing
• FT530: one relay for the alarm

• small datalogger with cradle for wall attachement
• data transfert through a special interface
• range: -30 to +70 °C (NTC)
• memory: 16000 values
• ambient operating conditions: -30 to +70 °C
• battery type: CR 2032 3V
• battery life: 500 days
• dimension: 60 x 38 x 18,5 mm, IP65

options

• software Comsoft 3 basic (Réf. 554 1766)
• starting set: datalogger, software ComSoft 3 basic, transfert interface, cradle, battery (Réf. 0563 1742)

• one channel with internal sensor, calibration protocol
• range: -35 to +55 °C (NTC)
• precision: ±0.5 °C (-20 to +55 °C), ±1 °C (-35 to -20.1 °C)
• resolution: 0.1 °C (-20 to +55 °C), 0.3 °C (-35 to -20.1 °C)
• memory: 1 million values
• ambient operating conditions: -35 to +55 °C
• battery type: mangan AAA type
• battery life: about 3 years
• dimensions: 89 x 53 x 27 mm, IP65

options

• printer Testo 575, with one paper roll and batteries (Réf. 0554 1775)
• SD-card for data transfer
• software ComSoft 3 with USB interface: Basic (Réf. 0554 1766), Professionnel (Réf. 0554 830), or CFR 21 Part 11 (Réf. 0554 821)
• Ethernet adapter

• datalogger with 2 channels: one internal sensor and connector for one external probe, with set
• range for the internal sensor: -35 to +55 °C (NTC sensor)
• range for external sensor: -40 to 120 °C (NTC sensor)
• precision internal sensor: ±0.5 °C (-20 to +55 °C), ±1 °C (-35 to -20 °C)
• precision external sensor: ±0.3 °C (-25 to +55 °C), ±0,5 °C (outside of the precedent range)
• memory: 1 million values
• ambient operating conditions: -35 to +55 °C
• batteries: mangan AAA type
• battery life: 3 years
• dimension: 89 x 53 x 27 mm, IP65

options

• printer Testo 575, with one paper roll and batteries (Réf. 0554 1775)
• SD-card for data transfer
• software ComSoft 3 with USB interface: Basic (Réf. 0554 1766), Professionnel (Réf. 0554 830), or CFR 21 Part 11 (Réf. 0554 821)
• Ethernet adapter

• datalogger for 2 external probes, with fixation set
• temperature range: -50 to 1000 °C with thermocouple type K, -50 to +400 °C with thermocouple type T
• precision: ±0.7% v.m. (+70.1 to +400 °C), ±0.5 °C (-50 to +70 °C)
• memory: 1 million values
• ambient operating conditions: -35 to +55 °C
• batteries: mangan AAA type
• battery life: 3 years
• dimension: 89 x 53 x 27 mm, IP65

options

• printer Testo 575, with one paper roll and batteries (Réf. 0554 1775)
• SD-card for data transfer
• software ComSoft 3 with USB interface: Basic (Réf. 0554 1766), Professionnel (Réf. 0554 830), or CFR 21 Part 11 (Réf. 0554 821)
• Ethernet adapter

• one channel data logger with internal sensor, fixation set, calibration certificate
• range: -40 to +70 °C (NTC sensor)
• precision: ±0.4 °C (-25 to +70 °C, ±0.8 °C (-40 to -25.1 °C)
• memory: 48000 points
• ambient operating conditions: -40 to +70 °C
• battery type: lithium
• battery life: about 5 years
• weight: 111 g
• dimension: 103 x 64 x 33 mm

options

• printer Testo 575, with one paper roll and batteries (Réf. 0554 1775)
• data collector Testo 580 with RS232 interface
• software ComSoft 3 with USB interface: Basic (Réf. 0554 1766), Professionnel (Réf. 0554 830), or CFR 21 Part 11 (Réf. 0554 821)
• Ethernet adapter

• same as Testo 177-T1 but with digital display
• weight 122 g

• 4 channels data logger with external sensors, fixation set, calibration protocolle
• range: -200 to +400 °C (sensor type T), -195 to +1000 °C (sensor type K), -100 to +750 °C (type J)
• precison: ±0.5% (+70.1 to +1000 °C), ±1% (-200 to -100.1 °C), ±0.3 °C (-100 to +70 °C)
• memory: 48000 points
• ambient operating conditions: 0 to +70 °C
• battery type: lithium
• battery life: about 5 years
• weight: 129 g
• dimension: 103 x 64 x 33 mm

options

• printer Testo 575, with one paper roll and batteries (Réf. 0554 1775)
• data collector Testo 580 with RS232 interface
• software ComSoft 3 with USB interface: Basic (Réf. 0554 1766), Professionnel (Réf. 0554 830), or CFR 21 Part 11 (Réf. 0554 821)
• Ethernet adapter

Description

Temperature wireless data logger Newsteo

The temperature logger can transfer the data directly to a monitoring computer by radio frequencies (monitoring mode) or can store the data in its memory (recording mode).

Up to 500 loggers can communicate with one RF-USB stick connected to the computer.

specification

• internal sensor
• temperature range: -40 to 70 °C, resolution 0.1 °C
• sample interval: 1 second to 4 hours
• memory: 32768 points
• min/max value
• pile Lithium Thionyle 1/2 AA ou AA depending on the model
• battery life: 2 years (for 1 mesurement/10 minutes), also depending on the temperature (a LOG21 at 60 °C has an autonomy of about 1 month).
• IP54
• dimension: 96 mm x 40 mm x 20 mm (antenna: 90 mm)
• RF range: 30 m to 1 km (there are different antenna sizes)
• frequency: ISM 868 MHz (Europe); 915 MHz (USA)
• possibility to use a magnet start the data recording

applications

• storage control
• transport of fresh, frozen food, pharmaceuticals...

Temperature + shock, model TRE 52

• temperature range : -40°C to +85°C, +/-0.3°C at 25°C
• acceleration: -16g to +16g
• signal range: 40 m

Like before but with external Sensor (Pt100, Pt1000,...).

Specifications

• temperature range: 250 to 1000 °C
• precision: depending on the sensor
• sample interval: 1 second to 4 hours
• memory: 32768 points
• min/max value
• battery Lithium Thionyl AA
• battery life: 2 years (for 1 mesurement/10 minutes)
• dimension: 96 mm x 40 mm x 20 mm (antenna: 90 mm)
• RF range: 30 m to 1 km (there are different antenna sizes)
• frequency: ISM 868 MHz (Europe); 915 MHz (USA)

• Incorporate an Ethernet/ LAN interface
• Can be connected to wired or wireless LAN
• 2 temperature channels
• External Sensor: -40 to 110°C
• Optional Sensor: -60 to 155°C
• Measurement Accuracy: ±0.3°C(-20 to 80°C)
• Measurement Resolution Display 0.1°C
• Recording Interval 1,2,5,10,15,20,30Seconds,1,2,5,10,15,20,30,60Minutes
• Recording Capacity 8,000 Readings x 2 Channels
• Recording Method Endless (Overwrite from the oldest data when recording capacity is full), One time Method (Stop recording when recording capacity is full)
• Power Source: Special AC Adaptor ( DC5V )
• Data Back-up: Saved for about 3 months with 1 lithium battery (CR-2032)
• Interface Wired LAN: 10 / 100 Base - TX RJ45 connector
• Wireless LAN:IEEE802.11b CF type Wireless LAN Card
• Dimensions: H55mm x W78mm x D39mm
• Weight 101 g ( Including one battery )
• Browser Functions View Temperature and Humidity Data in Graph Form , Start Recording, Download Data , Monitor Current Readings , Check Back-up Battery
• Warning Mail Function E-mail: Register up to 5 addresses to receive mail
• Power Consumption: About 290mA ( when using wired LAN )
• Security Access Controlled IP Address , ID Password Authentication
• Working Environment for Main Unit Temperature : 0 to 50°C Humidity : 20 to 80%RH (without condensation)

Wireless temperature sensor / datalogger, uses existing Wi-Fi networks. No need for cables. Installation is straightforward.

Specifications

• Range: 0°C to 70°C
• Resolution: 0.1°C (0°C-40°C)
• Accuracy: < ±0.5°C
• Operating temperature: 0°C to +70°C
• Up to 3 Years Life using a single Lithium AA battery (depending on settings and network quality)
• Data storage: at least 24 hours at sampling rate of once per minute
• Dimensions: 62mm x 62mm x 22mm
• Weight: 57 g
• Typical power emission: 33 mW
• Regulatory: FCC (USA)

Wi-Fi

• IEEE 802.11 b/g compatible (g-only not supported)
• Supported rates: 1, 2 Mbps only
• Security: WPA2-PSK (AES), WPA1-PSK (TKIP), WPA1+2 PSK (AES+TKIP), 802.1x EAP-FAST, WEP (40 bit, 104 bit)
• Addressing: IP v4 static or DHCP address
• Protocol used to communicate with server: SNMP/UDP, UDP
• Ports: 161-163 on both server and sensor

Wireless temperature sensor / datalogger, uses existing Wi-Fi networks. No need for cables. Installation is straightforward. For outdoor applications.

Specifications

• Range: -40°C to 70°C
• Resolution: 0.1°C
• Accuracy: 1 °C at 25 °C
• Operating temperature: -40°C to +70°C
• Up to 3 Years Life using a single Lithium AA battery (depending on settings and network quality)
• Data storage: at least 40 days of sensor data at sampling rate of once per minute
• Dimensions: 32mm x Ø 47mm
• Typical power emission: 33 mW
• Regulatory: FCC, CE, EN12830, EN61010-1

Wi-Fi

• IEEE 802.11 b/g compatible (g-only not supported)
• Supported rates: 1, 2 Mbps only
• Security: WPA2-PSK (AES), WPA1-PSK (TKIP), WPA1+2 PSK (AES+TKIP), 802.1x EAP-FAST, WEP (40bit, 104bit)
• Addressing: IP v4 static or DHCP address
• Protocol used to communicate with server: SNMP/UDP, UDP
• Ports: 161-163 on both server and sensor

• Range: -40°C to +150°C (Sensor Pt 1000)
• Accuracy : 0,3°C from -40°C to +150°C
• Resolution : 0.1°C
• Memory: 27.000 values
• Operating temperature: -40°C to +150°C
• Operating pressure: up to 20 bar
• Measuring mode: Endless, Start/Stop time, Start immediately until end of memory
• Dimensions: 48 x 48 x 24 mm
• Weight: about 70 g
• Battery: 3,6 V Lithium (exchangeable by user )
• Housing material: Stainless steel (V4A / PEEK)
• Protection class IP 68
• For the control and validation of autocalve, incubator, fridge...

Disposable data logger ITAG PDF with built-in USB connector and built-in PDF Generator

The data logger is delivered pre-programmed:

• Running time (24h, 72h, 7 days, 15 days, 30 days, 60 days)
• Upper and lower alarm limit (eg <2 ° C and> 8 ° C)
• Alarm delay time (default: 30 min.)
• Start time delay (default: 0 min.)

Technical data

• Measuring range -30 ° C to +70 ° C
• Accuracy: ± 0.3 °C from -20 °C to +30 °C, otherwise ± 0.5 °C
• Resolution: 0.1 ° C
• Data storage: 3 800 values
• Recording time: 1 hour to 60 days
• Measuring interval: min 10 sec to 60 min.
• Shelf life: 12 months
• Dimensions (L x W x D): 80 mm x 52 mm x 4 mm
• Weight: 16.5 g
• Water resistance: IP65
• System requirements: Adobe Reader ®
• Certification: calibration certificate, CE, RoHS
