Temperature and humidity measurement

Real-time USB Temperature & Humidity Monitor EL-USB-RT

  • range: -20 to +70°C and 0 to 100%RH.
  • The PC displays the temperature, humidity and dewpoint (the temperature at which water vapor present in the air begins to condense) in real-time and saves it to a file which can store up to 7 day's worth of data. This data file is overwritten at the beginning of each newlogging session. The software provides the option for the user to save the data file permanently to the hard-drive. Temperature, relative humidity and dew point can be graphed, printed and exported to other applications.
  • Users can set up high and low alarms within the software which can send emails, text alerts or audible alarms via the PC's internal speaker.


Temperature and humidity indicator Testo 608-H1

  • for humidity, dew point, temperature
  • humidity range: +5 to +95 % rH (probe type: capacitif)
  • resolution: 0.1 % rH
  • temperature range: 0 to +50 °C (NTC)
  • resolution: 0.1 ° C
  • operating temperature: 0 to +50 °C
  • batterie: 9 V
  • battery life: 8000 h
  • weight: 170 g


Temperature and humidity indicatorl Testo 608-H2

  • like the Testo 608-H1 with supplementary features:
  • calibration certificate (12 %HR and 76 %HR at +25°)
  • better precision: 2 %HR


Temperature and humidity indicator Testo 605

  • Humidity range: +5 to +95 % rH
  • Resolution 0.1 % rH
  • Temperature range: 0 to +50 °C (NTC)
  • Resolution 0.1 ° C
  • Ambient operating conditions: 0 ... +50 °C
  • Battery type: 3V-button (CR 2032)
  • Battery life: 200 h
  • Weight: 120 g


Temperature and humidity indicator Testo 625

  • Displays temperature relativ humidity and dew point
  • Max-/Min-values
  • Hold-button
  • Temperature range: -10 to +60 °C (sensor type NTC) or -200 to +1370 °C (sensortype Typ K)
  • Precision ±0.5 °C
  • Resolution 0.1 °C
  • Humidity range 0 to +100 % rH
  • Precision ±2.5 % rH (+5 to +95 % rH)
  • Resolution 0.1 % rH
  • Ambient operating conditions: -20 to +50 °C
  • Batterie type: 9V-Bloc, 6F22
  • Battery life: 70 h
  • Weight 195 g
  • Dimesions 182 x 64 x 40 mm


TH300

Temperature and humidity indicator TH300

  • temperature range: -30 °C to +85 °C
  • humidity range: 0 to 95 % RH
  • precision for temperature: ± 1 °C
  • precision for humidity: ±2 % from 0 to 60%, ±3% from 60 to 95%
  • dew point (calculated): -30 °C to 50 °C
  • dew point accuracy (calculated): ±2 °C from 30 to 95% RH
  • resolution: 0,1 °C and 0,1 % RH
  • respons time: 30 seconds for 63 % of full scale
  • record minimal and maximal temperature
  • ambient operating conditions: 0-50°C, 0 to 85 % RH without condensation
  • battery 9 V
  • battery life: 50 hours (switch off automatically afte 12 minutes)
  • indicator for the battey level


Temperature and humidity indicator Testo 635-1

  • moisture, temperature, material equilibrium moisture and pressure dewpoint in compressed air systems
  • up to 3 temperature or humidity probes with radio transmission can be displayed
  • measurement data can be transmitted by infrared to the Testo printer
  • cyclical printing of readings once a minute, for example
  • delivered with battery and calibration protocol


Infrared Temperature Indicator Testo 845/humidity

  • like the Testo 845 but with Integrated humidity module for measuring indoor air humidity and for determining dewpoint distance
  • humidity range: 0 ... +100 %HR
  • precision: ±2 %HR (2 ... 98 %HR)


Humidity measurement on wall, damp detector DampGuard®

  • For prevention of damage to walls caused by damp
  • Direct humidity measurement on the wall surface, detection of condensation
  • Colored leds indicate risk of damp developpement
  • Saves heating costs
  • Protects health, ideally suited for people prone to allergies and asthmatics
  • Simple to use
  • Battery life: 1 year


Humidity measurement Testo 606-1
  • wood moisture measurement with stored characteristic curves for beech, spruce, larch, oak, pine, maple
  • additional characteristic curves to locate wet points in building materials for cement screed, concrete, plaster, anhydrite screed, cement mortar, lime mortar, brick
  • range: 0 to 50 % (measurement of conductivity)
  • precision: ±1 %
  • resolution: 0.1
  • hold function
  • display illumination
  • self-test function
  • protective cap for safe storage
  • delivered with belt case, wrist strap and calibration protocol included


Humidity measurement Testo 606-2
  • like the Testo 606-1 with a few more features:
  • air temperature (sonde NTC probe)
  • temperature range: -10 to +50 °C
  • precision ±0.5 °C
  • resolution 0.1 °C
  • air humidity
  • humidity range: 0 to 100 %HR
  • precision: ±2.5 %HR (5 à 95 %HR)
  • resolution: 0.1 % HR
  • dew point calculation


Humidity measurement Testo 616
  • wood and material moisture
  • equipped with 10 characteristics curves for soft wood, hard wood, chipboard, anhydrite screed, cement screed, lime sand brick, aerated concrete, concrete, vertical hole brick and solid brick
  • measurement depth up to 5 cm
  • display is in percent by weight in comparison to the dry mass of the material
  • capacitv probe
  • deliverd with battery and calibration certificate
  • resolution: 0.1
